Arrow Hart Motor Controls and Disconnect Switches
Offering flexible and economical designs for both fused and non-fused applications, Eaton’s Arrow Hart motor control disconnect switches are built for use in harsh industrial applications to address the needs of safety, reduced downtime, and code compliance. Our industrial-grade, electrical motor controls feature durable lever handles and switch mechanisms that will withstand repeated use in harsh environments, with NEMA Type 4X housings that can be padlocked to OHSA lockout/tagout 1910.147 requirements. Additionally, our non-fused motor control disconnect switch and our new stainless-steel X-Switch are NSF listed for use in food processing.
The Arrow Hart X-Switch excels where standard industrial switches are most susceptible to fail: in physically abusive areas exposed to washdowns, extreme temperatures, chemicals and corrosive elements. Eaton motor control disconnect switches are built for use in harsh industrial applications to address the needs of safety, reduced downtime, and code compliance.
IP69K rated and NSF certified
X-Switch motor controls are IP69K rated for high temperature and high-pressure washdown. IP69K breather drain option available to prevent interior condensation build-up. The X-Switch is NSF-listed and IP69K rated making it ideal for the food and beverage industry’s processing areas.
Features:
- Heavy-duty motor control disconnect switches designed for long life
- The high-visibility red handle can be padlocked to meet OSHA lockout/tagout requirements
- Optional auxiliary contacts for PLC and VFD applications
- DIN-rail mounting system and compact size for flexible installation
- Mounting feet provide ¼” clearance for flexible positioning and mounting options per NEC 300.6(D)
- The gasket provides watertight protection and easy cleaning
- Compact NEMA Type 4X – 316L stainless steel enclosure and sloped top of the X-Switch are ideal for washdown environments
- Optional IP69K breather drain prevents interior condensation build-up
- Thermoplastic enclosure made from VALOX™ resin provides high impact strength and excellent corrosion resistance
